alumax 702 Aluminium Curtain Wall

Aluminium Curtain Walling

Comar curtain walling and window wall systems

Maxium offer a full design and installation of aluminium curtain walling ideal for schools, retail, commercial, leisure and all types of buildings.

With a full range of design options, colours and styles, you can turn an ordinary space in to something special with an aluminium glaze wall.

Comar Aluminium Curtain Wall and Window Wall Systems provide high performance curtain wall solutions for new and refurbished buildings. From high-rise applications to ground floor treatments, systems have been developed and tested to suit many environments, for all commercial and retail buildings.

Call on 01279 271192 for advice & quotes,

Product Details

High quality aluminium Curtain Walling with a range of 50mm wide mullions available in a choice of depths to meet the structural or wind-load requirements. Provides bespoke design solutions.

Stick assembly enabling fast site installation. Transoms and be square or profiled, as well as overlapping versions.

Comes with a purpose-designed mullion and transom for roof glazing or inlined facades.  Fast fabrication, as well as easy site installation, comes from a unique cleating and bracket arrangement.
Special drainage and drainage zones ensure weather protection and the correct drainage of any water to the outside.

The Ix and Iy values of the curtain walling mullions and transoms are some of the best on the market.

Designed, tested and audited to CWCT standards & recommendations

  • Air Permeability to EN12152
  • Water Tightness to EN12154 2400pa
  • Wind Resistance to EN13116 2400pa
  • Can achieve low U-Values and excellent sound insulation
Door Size RangeMin WidthMax WidthMin Height Max Height
Single inward and outward opening 300mm1470mm300mm2950mm
Double inward and outward opening900mm2830mm300mm2950mm


Panel Size Range                             Min WidthMax WidthMin Height Max Height
Fixed side solid panels300mm1225mm300mm2950mm
Fixed overhead solid panels900mm2830mm300mm1225mm
Fixed side glazed panels300mm1225mm300mm2950mm
Fixed overhead glazed panels300mm2830mm300mm1225mm

Doors are available in a choice of standard RAL colours from the Interpon / Akzo-Nobel powder range. Minimum paint thickness is approx. 30 – 50 Microns. Optional include woodgrain colours, textured powder coating and the full RAL colour range.

Steel Door Colour Chart
